HS Armor Ballistic Resistant FRP Panels

HS Armor panels are available in three levels of protection that correspond to the UL752 ballistic resistance performance standard as shown in the table below. Higher levels of protection up to UL752 Level 8 are available by layering panels.

Our HS Composite Armor panels are constructed of multiple layers of fiberglass reinforcements in a proprietary resin system to create rigid panels with exceptional ballistic resistance. The composite construction of the HS Armor panel not only stops the bullet but also encapsulates it to prevent dangerous ricochet back.

HS Composite Armor Specifications:

           Nominal Thickness       Weight PSF            Ammunition                 Ballistic Rating

               1/4"                   2.51 lbs.          9 MM             UL752 Level 1

              3/8"                    4.10 lbs.        .357 Mag         UL752 Level 2

              1/2"                    5.10 lbs.       .44 Mag        UL752 Level 3 / NIJ 3A

Materials of Construction

Resin................................ Proprietary Low Profile Polyester

Fiber Reinforcements........Layers of 0-90 degree "E" glass

Manufacturing Process......Pultrusion

Surface...............................Textured

Color...................................Standard Off White / Tan

Independent Testing

 UL Underwriters Lab  UL752 Ballistic ResistanceLevels 1-3

 ASTM E-119-09 c                      Fire Rated for 1 Hour

 ASTM E-84-08c                     Flame Spread Rating of 45

 ASTM E-84-08a                  Smoke Generated Rating 165

 NFPA & IBC  Class B Fire Rating
